Industrial -40º / +85º

6C-SFP-0310D 1000GBASE-LX/LH SFP 1310nm 10km Optical Transceiver Module

Features
1. DDM Duplex LC Connector
2. Max. Power Consumption 1W
3. For Campus Networks, Enterprise LAN Networks, and other optical links
4. Compatible with 100+ Vendors
5. Compliant with SFF-8472 and SFP MSA

Application
Campus Networks, Enterprise LAN Networks

Parameters Table
Part Number SFP-1G-LX/LH Vendor Name 6COMGIGA
Form Factor SFP Data Rate 1.25Gbps
Wavelength 1310nm Distance 10km/20km
Connector LC Duplex Cable Type OS2 SMF
Transmitter Type FP Receiver Type PIN
TX Power -9 ~ -3dBm Receiver Sensitivity - -22dBm
Power Consumption - 1W Temperature 0 to 70°C (32 to 158°F)
DDM Support Bit Error Ratio (BER) 1E-12
Protocols IEEE 802.3z, SFF-8472, SFP MSA Compliant Warranty 3 Years
