Standard IEC/EN 60947-5-1
Number of contacts NO + NC
Rated voltage Ue, V 240AC, 60DC
Rated frequency, Hz 50/60
Commutation wear resistance 6 000 - electric
10 000 - mechanical
Conventional thermal current Ith, А 2.5
Rated current Ie, AC-15 0.5A at 240V
Rated current Ie, DC-13 0.15A at 60V
Rated voltage of the insulation Ui, V 250
Rated pulse current output voltage Uimp, V 2 500
