Vibration detector SS14

SS14 is a detection device of shocks and vibrations. Is used to protect fixtures, windows, box, or any passage where is needed detect break-in attempts by vibrations or strong shocks.
It also equipped with a separate second reed contact normally closed.

Features:
- Dimensions of 77x36x20 mm
- 13.8 Vcc power supply
- Standby current - 9mA
- Max current - 18mA
- RFI protection 30V/m (20 MHz - 2000 MHz)
- Tamper contact 0.2 A - 24 Vcc
- Alarm contact Max 40 mA - 30 Vcc
- Temperature -20°C a +50°C
- ABS housing

Applications and usage:
- Intrusion detection
- Vibration detection
