DIGITUS Industrial mini GBIC (SFP) Module, 1.25 Gbps, 20km
Product number: DN-81011
EAN: 4016032307587
1.25 Gbps SFP Module, Singlemode, Industrial vers. LC Duplex Connector, 1310nm, up to 20km

The plug and play fiber connection

The Plug - Play fiber optic link enables quick installation
Sends data in high quality and additionally provides excellent reliability
Distance up to 20 km at a maximum data rate of 1.25Gbps
Operating temperature: -40 °C - +85 °C

DESCRIPTION
The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.

TECHNICAL DETAILS
Mini GBIC SFP (Small Form Factor Pluggable) module
Compatible with the following manuafacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , ENTERASYS, RIVERSTONE , Unifi, Ubiquiti, ZyX
High quality and excellent reliability
1.25 Gbps Maximum Data Rate
Compliant to IEEE 802.3z Gigabit Standard
Class 1 laser product compliant with EN 60825-1
Easy plug-and-play installation
MSA (Multi Source Agreement) compliant
Hot pluggable
Connector: 1x LC Duplex
1000Base-LX - For Long Haul
Wavelength: 1310nm
Transmission power: minimum -8 dBm, maximum -3 dBm
Sensitivity receiving power: minimum -24 dBm
For a Distance of up to 20km
Suitable for 09/125µm Singlemode Fiber Cables
Safe fast-locking mechanism
3.3V power supply
Operating temperature: -40 °C - +85 °C
