Efento pulse counter is used to remotely monitor water flow through a water meter in order to control the water consumption and related expenses. You can connect it to any water meter equipped with Standard output (SO) or pulse generator. The solution is dedicated for dispersed facilities, in which control of the water consumption is impossible or expensive. Analysis of meter’s data allows you to decrease water bills and quickly detect anomalies and minimize the effects of flooding. The sensor can simultaneously work with up to three water meters. By default, each counted pulse represents one liter of flowing water (l). Data is presented in the form of water flow (in liters per minute) or in the form of water consumption over a selected period of time (in m³).

You can use a free mobile application to configure the device and read the data from its memory. If you add Efento Gateway, you can build a remote monitoring system.

VERSATILITY
The counter can cooperate with any device equipped with a pulse output

UP TO 3 CHANNELS
Simultaneous operation with up to 3 water meters

RADIO MODULE
Communication: Bluetooth Low Energy (BLE)
Radio frequency: 2,4 GHz
Power: 2,5 mW (4 dBm)
Range: up to 100 m (LOS)
Communication standard: Bluetooth Smart (Bluetooth Low Energy, Bluetooth 4.0)
Transmission frequency: 1 s

MINIMUM PULSE DURATION
5 millisecond
MAXIMUM PULSE DURATION
500 millisecond

SUPPORTED COUNTERS
NO (Pull-up 3.6V)

BATTERY
Battery: 3,6 V, size AA, capacity 2 700 mAh (replaceable)
Battery operating time: at least 5 years (measurement interval: 15 min)

DIMENSIONS
27 x 71 x 71 mm
Weight: 80 g
