DIGITUS 25G DAC Cable SFP28 5m
Product number: DN-81245
EAN: 4016032478836
DAC Cable SFP28 5 M DAC Cable 25 G 5m

It is suitable for short reach connection between two SFP28 ports in 25G interconnecting networking applications.

5m transmission
AWG 26 Twinax cable
Up to 25.88243 Gbps data rate
Hot-pluggable SFP 20 PIN footprint
Operating temperature: 0~70°C
Imporved Pluggable Form Factor (IPF)
Power: +3.3V supply voltage and SFF-8402
Connector is compatible with SFF-8432 specification

DESCRIPTION
DIGITUS® 25G SFP28 Passive Direct-Attach Copper Twinax Cable are a high-performance, energy-saving, short-range connectivity solution 25G Etherne application, switches, high peroframnce computer, dtat sotrage arrays and telecom system. It consists of a shielded twinax copper cable with pluggable connectors on either end. Passive DAC cable have no electrical components built into the cable assembly and recommend for short transmission distance. Typically 1~2m and max. 5m lengths.

TECHNICAL DETAILS
Number of Lanes : Tx - Rx
Connector Type: SFP28 to SFP28
Channel Data Rate: 25.88243 Gbps
Operating Temperature: 0 to +70°C
Otorage Temperature: -40 to +85°C
Supply Voltage: 3.3V nominal
Power comsumption less than 0.5W
Compliant with MSA SFP28
Electrical Interface: 20 pins edge connector
Management Interface: Serial, I²C
Connector is compatible with SFF-8432 specification
Compatible with Allnet, CISCO, 3COM, D-LINK, Dell, Edimax, Etherwan, ENTERASYS, EXTREME, FINISAR, FORCE 10, Fortinet, HUAWEI, IBM, JUNIPER, LINKSYS, NETGEAR, NORTEL, RIVERSTONE, ZTE, ZYXEL
