Overview:



Behpex offers premium CAT.8-CAT.5e Toolless Keystone Jack. It is designed to be assembled mounting-friendly without any tool. The jack saves you the hassle of using a punch down tool and increases the installation efficiency.



Specifications:



Connector Type Category 6 Shielded Type Shielded
Cable Type Round, Shielded Conductor Type Solid | Stranded
Color Red Termination Type IDC
Contact Base Material Phosphor Bronze Contact Plating Material Gold
Transmission Standards ANSI/TIA-568.2-D | ISO/IEC 11801 Class E Wiring Scheme T568B/T568A
Fire Rated UL 94-V0 | UL 94-V2 PoE Compatibility PoE, PoE+, PoE++
Compatible Cable Diameter, Maximum 9.0mm Compatible Insulated Conductor Diameter, Maximum 1.6mm
IDC Wire Gauge 26AWG-23AWG Mating Durability Mini. 750 Cycles
Product Compliance CE, RoHS, REACH, UKCA Package Type Polybag | Box
Operating Temperature -20℃ to +60℃ Installation Temperature 0℃ to +50℃
Operating Humidity Range 0% to 90% RH, Non-Condensing Storage Humidity Range 0% to 90% RH, Non-Condensing


Key Features:




1, Easily terminate in the field with IDC for 23AWG-26AWG with no special tools.


2, Toolless keystone jack for easy installation.

3, Compatible with both T568A and T568B wiring schemes.

4, 50U gold plated contact.

5, Phosphor Bronze IDC Contacts ensure excellent conductivity, durability and outstanding resistance against wear or corrosion.
