Highlight Features
PTP Max. 15 km Working Distance
PTMP Easy Pairing All in 30 sec
24 V Passive PoE
IP65, 6 kV Surge Protection and ±24 kV ESD against Harsh Environment
220.32 km/h (137 mph) Wind Survivability
All-in-one Cloud Management Simplifies the User Journey

Key Specification
Dimensions (Diameter x Length, including mounting kit) 368.5 x 271 mm（14.5 x 10.7 in.）
Working Distance 15 km
Gain 23 dBi
Angle H: 9°, V: 9°
Capacity 5 GHz, 867 Mbps
Port 1 x 10/100/1000 Mbps
IP Rating IP65
Operation Temperature* –40℃ to +70℃ (–40°F to +158°F)
ESD ±24 kV Contact/ Air
Surge Protection 6 kV
Power 24 V Passive PoE
LED 3 Signal Strength LED 1 LAN LED 1 System LED
Pairing Method One-touch pairing in 30 sec App pairing in 2 mins
Certification CE
