Power supply output 2 A / 27.6 V DC / 56.8 W - for intermittent operation – Imax b (5min)
1.6 A / 27.6 V DC - for continuous operation – Imax a
Standards Certification with Fire protection standard EN54-4
Certification with Smoke extraction and ventilation standard EN12101-10
Certificate of constancy of performance CNBOP-PIB No 1438-CPR-0628
Certificate of approval CNBOP-PIB No. 5222/2024
Battery charging current 0.4A
Battery 2 x 7Ah
Current consumption by PSU systems 52mA max.
Efficiency 88%
Dimensions 330 x 305 x 82 [+/-2 mm]
distance from surface: 8 mm
Protections SCP, OLP, OVP, UVP, tamper – opening of enclosure
Technical outputs relay type EPS – AC power failure
ALARM – collective failure
Technical input EXTi – external failure
Closing Key lock
Installation surface-mounted
Indication LED optical indication
Material steel DC01, 1mm, RAL3001 (red), metallic
Protection grade EN60529 IP 30
Warranty 3 years
