NS5 black
Surface junction box with the capability for mounting using HNS hooks 75x75x40 mm, IP54

Cat. No.
35360107
EAN code
5907813232329
Name of item
NS5 black
Qty.
110 pcs.
Colour
black
Width
75 mm
Length
75 mm
Height
40 mm
Material
cover - polipropylene / body - polyethylene
Material properties
halogen-free / self-extinguishing / resistance to UV radiation
Resistance to heat
650 °C
Protection class
IP54
Mounting
On cable tray using HNS hooks. Mounting with the use of bands or Ø 6mm scews.
Rated voltage
400 V
Max rated cross-section
2.5 mm²
Operating temperature
-15 °C...+35 °C
Additional information
12 knockouts ⌀16
