Input and Output
Wireless Protection Zone
Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)

Port
Buzzer
Hub: Built-in
Button
Hub: 1 × reset, 1 × power, 1 × AP
Keyfob: 4 (Home, Away, Disarm, and SOS)
Door Detector: 1 × power button
PIR Detector: 1 × power button
Indicator Light
Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)
Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)
Door Detector: 1 × green alarm indicator
PIR Detector: 1 × green alarm indicator
Storage battery
Hub: Built-in lithium battery
Network Mode
Hub: Ethernet, Wi-Fi and Cellular network (Supports installation of dual SIM cards. Only one card can be enabled at a time)
Network Port
Hub: 1 × RJ-45 10 M/100 M Ethernet port

Function
Network Protocol
Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP
Offline Cache
Hub: Max. 50 entries (ANR)
Power Failure Protection for Configured Parameters
Hub: Yes
Remote Update
All: Cloud update
Video Linkage
Hub: Yes
SMS
Hub: Yes (up to 5 phone numbers)
Phone Call
Hub: Yes (up to 5 phone numbers)
Low Battery Alarm
All: Yes
Tamper Alarm
Hub: Yes
Door Detector: Yes
PIR Detector: Yes
User Management
Hub: Share function for App users
Search
Hub: Searching push messages, device status, and program version. Detecting signal strength.
Keyfob: Signal strength detection
Door Detector: Signal strength detection
PIR Detector: Signal strength detection
Arm and Disarm
Hub: App; keyfob; schedule

Wireless
Carrier Frequency
All: 868.0 MHz–868.6 MHz
Transmitter Power (EIRP)
All: Limit 25 mW
Communication Distance
Hub: Up to 2,000 m (6,561.68 ft) in an open space
Keyfob: Up to 900 m (2,952.76 ft) in an open space
Door Detector: Up to 1,200 m (3,937.01 ft) in an open space
PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space
Communication Mechanism
All: Two-way
Encryption Mode
All: AES128
Frequency Hopping
All: Yes

Wi-Fi
Wi-Fi Standard
IEEE 802.11b/g/n
Wi-Fi Frequency Range
2400-2483.5 MHz
Wi-Fi Power Transmission
≤20 dBm@2400-2483.5 MHz

Cellular Network
Cellular Network Standard
GSM/WCDMA/LTE
Frequency Range
GSM: 1,800/900 MHz;
Transmitter Power (EIRP)
Power class0: 30 dBm±3 dB (GSM900)
Power class5: 33 dBm±3 dB (GSM1800)

Peripherals
External Zone
Door Detector: 1-channel dry contact input

Temperature
Measuring Range (Temperature)
Door Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
PIR Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
Measuring Precision (Temperature)
Door Detector: ± 1 °C (± 33.8 °F)
PIR Detector: ± 1 °C (± 33.8 °F)
Resolution (Temperature)
Door Detector: 1 °C (33.8 °F)
PIR Detector: 1 °C (33.8 °F)

Specification
Sensor
Door Detector: Reed switch
PIR Detector: Dual elements low-noise PIR sensor
Test Mode
Door Detector: Yes
PIR Detector: Yes
Scenario
Door Detector: Non-metal doors
Movement Distance
Door Detector: - 40 mm (1.57-)
Detection Mode
PIR Detector: PIR
Detection Range
PIR Detector: 12 m (39.37 ft) (90°) with installtion height of 2.2 m (7.21 ft)
Detection Speed
PIR Detector: 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)
Pet Immunity Level
PIR Detector: ≤ 18 kg (39.68 lb)
White Light Resistance Level
PIR Detector: 6500 lx
Two-way Digital Temperature Compensation
PIR Detector: Yes, no attenuation of detection distance in high temperature
Sensitivity
PIR Detector: 3 levels adjustable

General
Power Supply
Hub: 12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)
Keyfob: CR2032 battery
Door Detector: CR123A battery
PIR Detector: CR123A battery
Battery Life
Hub: Storage battery standby for 12 Hours
Keyfob: 5 years
Door Detector: 5 years
PIR Detector: 4 years
Power Consumption
Keyfob: Max. 85 mW
Door Detector: Max. 70 mW
PIR Detector: Max. 75 mW
Operating environment
Hub: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)
Keyfob: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Door Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
PIR Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Operating Humidity
All: 10%–90% (RH)
Product Dimensions
Hub: 163.0 mm × 163.0 mm × 32.0 mm (6.42-- × 6.42-- × 1.26--) (L × W × H)
Keyfob: 60.0 mm × 39.5 mm × 15.0 mm (2.36-- × 1.56-- × 0.59--) (L × W × H)
Door Detector: 100.2 mm × 20.8 mm × 20.3 mm (3.94-- × 0.82-- × 0.80--) (L × W × H)
PIR Detector: 104.0 mm × 60.0 mm × 50.0 mm (4.09-- × 2.36-- × 1.97--) (L × W × H)
Packaging Dimensions
Hub: 219.0 mm × 187.0 mm × 91.0 mm (8.62-- × 7.36-- × 3.58--) (L × W × H)
Keyfob: 135.0 mm × 98.5 mm × 27.8 mm (5.31-- × 3.88-- × 1.09--) (L × W × H)
Door Detector: 135.0 mm × 98.5 mm × 27.8 mm (5.31-- × 3.88-- × 1.09--) (L × W × H)
PIR Detector: 135.0 mm × 98.5 mm × 56.8 mm (5.31-- × 3.88-- × 2.24--) (L × W × H)
Installation
Hub: Wall mount; Desktop
Door Detector: Bracket mount
PIR Detector: Wall mount
Net Weight
Hub: 0.38 Kg (0.84 lb)
Keyfob: 20 g (0.04 lb)
Door Detector: 70 g (0.15 lb)
PIR Detector: 100 g (0.22 lb)
Gross Weight
Hub: 0.8 Kg (1.76 lb)
Keyfob: 65 g (0.14 lb)
Door Detector: 115 g (0.25 lb)
PIR Detector: 170 g (0.37 lb)
Casing
All: PC + ABS
Certifications
All: CE
