Standards:
●Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7, ETSI standard.

Feautures:
●Exquisite design with precise dimension and craftsmanship;
●Steel front - rear door without hole;
●Adjustable feet and heavy duty castors are available at the same time;
●Several lockable cable entry on top cover and bottom panel with adjustable sizes;
●Optional plinth enables cabinet to stay in a fixed position, meeting requirements of under-base cable entry/ventilation and prevention;
●Efficient cabinet baying kit(patent);
●Removable side panels, easy to install and maintain;
●Around 1/2~2/3 of original assembled volume when flat pack.

Main material:
●SPCC cold rolled steel;
●Thickness: mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.

Surface finish:
●Degreasing, pickling, phosphoric, powder coated;

Degree of protection:
●IP20

Loading capacity:
●Static loading: 800KG
