Property States Quota Test method
Tensile strength (MPa)
unaged ≥10.3MPa
ASTM D2671

Heat-aged ≥6.9MPa
Ultimate elongation（%）
unaged ≥200%
Heat-aged ≥100%
Voltage withstand(V) unaged 2500 V,60s,Pass UL224
Dielectric strength (MV/m)
unaged ≥19.7
ASTM D2671

Heat-aged ≥15.8
Volume resistivity (Ω-cm) ≥10 14 ASTM D2671
Water absorption(%） Unaged ≤1.0 ASTM D 570
Corrosion Unaged Pass UL 224
Heat shock Unaged No flowing or dripping UL 224
Low temperature flexibility Unaged No cracks UL 224
Flammability unaged S3 DIN 5510-2


Printing Ribbon Description:

KHN85— is an ultra- high durability black resin thermal transfer ribbon, tested and approved for use on wire marker
sleeves as well as cable marker tags.
The max storage temperature: -5°C---40°C
Operating temperature: 5°C----35°C
The delivery temperature: -5°C ----45°C
Complied standards: SAE AS 81531 and MIL-STD-202F/215K
Ribbon width: 100 mm
Ribbon length: 300 m
Printable area: 100% full area
Internal diameter：25mm
Outside diameter: 62mm
Ink: Resin
Standard color: Black
Ribbon wind direction: Ink exterior
