WU-AB 06-100/T-EN54
Quick mounting
Highest reliability
BS 5839

Flush-mounted wall speaker with a black ABS-plastic housing for voice alarm applications, certified EN 54-24, suitable for voice announcements and background music with excellent sound quality in buildings.

Flush-mounted wall speaker with a black ABS-plastic housing for voice alarm applications certified EN 54-24, suitable for voice announcements and background music with excellent sound quality in buildings. The WU-AB 06-100/T-EN54 is designed with two independent speakers and 100V transformers to enable the economic operation of two separate speaker lines (A/B lines) for the highest security demands. In case of a failure of one speaker line, the redundancy of the chassis and the transformers will guarantee unimpaired function.

The 2 x 6W powered speaker is equipped with two full-range loudspeakers and two 100V transformers with 3 power adjustments, each. For additional reliability, a 2x2-pin ceramic block, and thermal fuses are provided and the speaker chassis are impregnated against wetness. The speaker is also secured with protection class IP 21C against the security risks of environmental influences.

The connecting cables can be supplied through 2 rubber grommets on each side of the rear housing. The speaker is also compliant with the British Standard BS 5839, Part 8. Quick and easy mounting with screws.
