Technical Specification
Electrical
Working Voltage
24V DC
Current
Monitoring current: ≤ 300μA
Operating current: ≤ 4.5mA
Capacity of the Output Contact
24V/2A/25ms
Indicator
•Input indicator: Red LED flashes once every 6 seconds, and flashes once every 2 seconds when malfunctioned, remains lit after receiving feedback
•Output indicator: Red LED is constantly off when works normally, and flashes once every 2 seconds when malfunctioned, remains lit after receiving start signal
Communication
Wiring
Two-wire, polarity-free
Addressing Method
Electrical encoder
Address Range
1–254
Communication
Distance
≤ 1500 m
Environment
Operating Temperature
–10°C to +55°C (+14°F to +131°F)
Storage Temperature
–20°C to +65°C (–4°F to +149°F)
Operating Humidity
≤ 95% RH (no condensation)
Construction
Color
White
Dimensions (with base)
90 mm × 90 mm × 37 mm (3.54- × 3.54- × 1.46-)
Weight (with base)
127 g (0.28 lb)
Certifications
CE
